Industrial Jetson Thor AI System With Dual 10GbE
Key Features
- NVIDIA Jetson T5000
- Up to 2070 FP4 TFLOPS
- 128GB LPDDR5X Memory
- 1TB NVMe Storage
- Dual 10GbE + 100Gbps QSFP28
- Supports 8x GMSL2 Cameras
Overview
The Aetina AIE-KT78/68 is an industrial Edge AI system powered by the NVIDIA Jetson T5000, delivering up to 2070 FP4 TFLOPS of AI performance. It features a 14-core ARM Neoverse V3AE CPU, 128GB LPDDR5X memory, and 1TB NVMe storage.
Need Assistance?
- +44 (0)1527 512 400
Specifications
System
Module Compatibility:
NVIDIA Jetson Thor (Jetson T5000) 128GB (AIE-KT78).
NVIDIA Jetson Thor (Jetson T4000) 64GB (AIE-KT68).
AI Performance:
2070 FP4/TFLOPS / 1035 FP8 TFLOPS (AIE-KT78).
1200 FP4/TFLOPS (AIE-KT68).
CPU:
14-Core ARM Neoverse V3AE (64 bit) (AIE-KT78).
12-Core ARM Neoverse V3AE (64 bit) (AIE-KT68).
Memory:
128GB 256-bit LPDDR5X (AIE-KT78).
64GB 256-bit LPDDR5X (AIE-KT68).
Storage:
1 x M.2 M-Key 2280 (NVMe 1TB built-in).
Expansion:
1 x M.2 M-Key 2280 (NVMe 1TB built-in).
1 x M.2 E-Key 2230 (WiFi/BT).
1 x M.2 B-Key 3042/3052 (LTE/4G/5G).
1 x Micro SIM card slot.
I/O
Display:
1 x HDMI 2.0b.
1 x DP 1.4a.
Camera:
2 x mini-Fakra (Optional).
Ethernet:
2 x RJ-45 10GbE.
1 x RJ45 1GbE EtherCAT.
USB:
1 x USB-C (OTG Only).
4 x USB-A 3.2 (Gen 2).
Other:
1× QSFP28 slot (T5000: 4× 25 GbE) (T4000: 3× 25 GbE).
1 x HD Audio-in/out.
2 x RS232/RS485/RS422.
2 x Isolated CAN FD (T5000 model only).
4 x DI/DO (Isolation) @3.3V.
2 x UART @ 3.3V.
2 x I2C @ 3.3V.
1 x OOB (By request).
Power
Power Input / Connector:
9V-48V.
Environmental
Operating Temperature:
-25°C ~ +55°C (-13°F ~ +131°F).
Storage Temperature:
-40°C ~ +85°C (-40°F ~ +185°F).
Humidity:
95% (Non-condensing).
Certification:
CE / FCC (Class A) / UKCA.
Mechanical
Dimension (W x D x H):
220 x 143 x 80 mm.
Weight (Net):
3.171 kg.
Other Features
Software Support:
Linux.
